Step-thru Fat Tire Commuter
Easy commuting and maximum comfort
Foldable
Folded: 38.6"x18"x28"
750W
Brushless Motor
720Wh
48V/15Ah Battery
55+ Miles
Extended Range
Class 3
5-level PAS
330lbs
Max Load
Brushless Motor
The powerful rear motor delivers 750W of continuous power and even higher peak power for short periods when needed. Now you can conquer hills faster, gain speed quicker, and experience a more powerful ride throughout - even at lower speeds.
750 W
Motor Power
70 Nm
Max Torque
48V 15Ah Lithium Battery
The battery placed on the underside gives the S5 better handling. It charges in just 4 hours and can be easily removed from the frame or inserted without tools. You can get up to 50+ miles of range on a single charge, depending on your PAS mode and riding style.
55+ Miles
Per Charge
720 Wh
Total Capacity
Key features of the Build
Reliable components at a fair price.
Shimano Gear System
Shimano's 7-speed cassette and throttle shifting make for a smooth and easy ride. Combined with the pedal assist, you can ride at the speed that works best for you.
20x4" CST Fat Tires
Tread groove design provides excellent handling and grip with anti-slip function. Multi-layer tires are safer and better protected from punctures.
Hi-end Mechanical Brakes
High-performance braking for a variety of riding styles. The Q5 brakes ensure full stopping power in any weather conditions. Maximum control on rough, technical terrain.
YL80C LCD Display
The display provides clear and accurate data such as assistance level, speed, battery charge, and distance. Check your riding status at any time and ride your e-bike even during the rain.
Comfortable Saddle
A comfortable saddle is adjustable and combined with shock absorption.
Integrated Brake Light
The automatic brake light is activated as soon as you apply the brakes. It can be turned on and off via the display. The rear lights are bright and make driving at night safer.
Durable 42T Aluminum Crankset
Durable aluminum cranksets protect the chainring and help the chainstay ride over rough terrain. The improved 42T crank reduces the risk of pedaling to nothing while riding.
Front Basket
The S5 is perfect for the commute or a quick trip to the supermarket. Fill your basket with snacks, a pint of ice cream and some fudge - and hit the road.
Half-Twist Throttle
The half-twist throttle lever prevents accidental engagement.
Pedal Assist System (PAS)
Pedal assist is a bike feature that puts the power of the motor right in your pedal stroke.
Pedal assist can be activated by selecting a PAS level using the PAS selector buttons. The higher the PAS level, the more power is delivered with each pedal stroke, and the easier it is to ride. There is also an option to select no pedal assistance (PAS level 0) and use the throttle only or ride without assistance from the motor by pedaling.
Pedal Assist System (PAS)
Pedal assist is a bike feature that puts the power of the motor right in your pedal stroke.
Pedal assist can be activated by selecting a PAS level using the PAS selector buttons. The higher the PAS level, the more power is delivered with each pedal stroke, and the easier it is to ride. There is also an option to select no pedal assistance (PAS level 0) and use the throttle only or ride without assistance from the motor by pedaling.
| Hub Motor 1300W (Peak) 1000W (Sustained), |
Battery 48V/15Ah(720Wh) lithium battery |
|
| Display LCD display with USB charging |
Throttle Thumb throttle |
Charger US standard 2.0 A smart charger |
| Pedal Assist 3, 5, 7, or 9 levels (default 5) |
Controller 48V/25A |
Crank Set 220mm w/52T |
| Frame 6061 Aluminium |
Tires CST 20"*4.0" Fat Tire |
Shifter Shimano 8-Speed |
| Brake Dual Piston Hydraulic Brakes |
Front Fork Suspension with Adjustable Lockout |
Kickstand Heavy duty aluminum |
| Freewheel 12-32T 8-Speed |
Pedal Wellgo Aluminum Platform |
Saddle Soft and comfortable |
| Front Light 48V LED light |
Rear Light Integrated Taillight |
Speed Up to 28 MPH |
| Wiring Water resistant connectors and wiring harness |
Rims Double Wall Magnesium Alloy Wheels |
Included Battery, charger, assembly guide,user manual |
Tesgo ebikes are built to the IPX6 water-resistant standard. IPX6 means that your bike is resistant to water splashes from any direction. Which means it’s OK to ride or park your ebike in the rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be submerged or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike.
Battery
48V/15Ah (720Wh) lithium battery
Charger
US standard 2.0 smart charger
Controller
48V/18A
Motor
750W brushless hub motor
Display
YL80C LCD display
Range
Throttle only: 28-37 miles
PAS: 43-55 miles
Pedal Assist
5 levels
Sensor
12 Magnet Cadence Sensor
Recommended Rider Heights
5'1"- 6'4"
Gosen electric bikes are IPX6 waterproof. IPX6 means that your bike is splash-proof from all directions and you can ride your e-bike in the rain. Water splashes from a wet road or raindrops cannot harm it. Do not submerge the bike under water and do not subject it to pressure. Do not clean the e-bike with a high-pressure cleaner or sprayer.
Functional Step-Thru Folding Electric Bike
The easiest all-terrain e-bike from forests to sandy beaches and dense snow.
FAQs
Customer Reviews
Aug 26, 2023 6:37 AM
I took the S5 bike out for a long ride this weekend for about a 30 mile round trip. The trail I took was almost all flat. By the time I got back home, my battery display showed that I still had 2 bars left on the charge. I did not use the power assist too much. The battery started off with full bars. One thing I noticed is that if you take a long ride on a bumpy trail, you should get a wider, more comfortable seat if you do most of your riding sitting down. I was able to get the bike to over 30 miles an hour and I felt pretty comfortable and stable doing it. Being able to step through the bike to get on and off is a really nice convenient feature. Im 200 lbs and the acceleration was pretty impressive for a Ebike. The one thing that needs to Figured out, is when you do want to carry the bike in your car trunk (and your doing it alone) and the bike is unlatched in half, It is very awkward to pick up. The bike wants to open back up again when picked up. It Would be nice to have some sort of lock to keep it folded so it wont open up. Right now i used a strong Bungee cord. Other than that its been very fun. I would recommend this as a daily commuter to anyone.
First I was a little worried about how everything would work, so I did some reading before I got on the e-bike to ride. I was shocked how it felt for a bigger bike. So my wife took it and she liked it and in a few days I hade another one in my garage. It’s a blast to get out again and not worry about going up the big hills.I must say we love it. Thanks for the awesome ride, keep making e-bike they are amazing 👍👍👍👍👍🇨🇦🇨🇦🇨🇦🇨🇦
Est-ce que vous prévoyez avoir la couleur rouge ou blanc bientôt le Gossen S5
It arrived soooo quickly I was shocked. It has everything including kick stand. The packing was amazing and I'm now charging battery! Can't wait I've been a motorcycle driver ( drove my Harley across America in 2009) so expect the transition to be easy and it will provide me a more healthy lifestyle. I can't wait to explore all the trails around my home town!
Thank you for your trust and support. ❤
Easy unboxing and setup. Great customer service and resolved issues expediently. Great looking bike and is easy to ride. Looking forward to using it for grocery shopping.
